CATEGORY OF SERVICE, LOCATION:

Soil, soil gas, groundwater assessment, and high-resolution site characterization (HRSC) for a former dry cleaner in a commercial shopping center, Yuba City, CA.

TYPE OF CLIENT:

Former Dry Cleaners Property Owner under Site Cleanup Subaccount Program (SCAP) grant funding

BACKGROUND:

The former dry cleaner operated for approximately 20 years. Previous environmental investigations at the Site revealed the presence of dry cleaning solvent in all media. The extent of impact was unknown. Trinity was hired to perform an additional investigation of all media to determine the lateral and vertical extent of impacts, develop a Conceptual Site Model (CSM), and develop a Remedial Action Plan (RAP).

hIGH-RESOLUTION SITE CHARACTERIZATION (HRSC)

CLIENT GOAL FOR PROJECT:

The property owner and SCAP want to have the characterization and remediation completed in a timely manner to close the case with the Central Valley Regional Water Quality Control Board (CVRWQCB) and allow the former dry cleaner building to be renovated and rented to a new tenant.

PROJECT APPROACH:

Trinity developed a Work Plan Addendum for the existing Site work plan and provided it to the CVRWQCB and SCAP for review. Both agencies approved the proposed scope of work, and the client was awarded a SCAP grant to reimburse the cost of the project.
Trinity implemented extensive high-resolution site characterization (HRSC) using a Membrane Interface Hydraulic Profiling (MiPHT) tool and post-confirmation sampling to determine the nature and extent of impacts to soil, soil vapor, groundwater, and indoor air.
Trinity worked closely with SCAP and the CVRWQCB throughout the investigation to adjust the work scope based on field data and observations.
Trinity developed a CSM for the Site based on the data collected during HRSC activities and determined that a significant portion of dry cleaning solvent present in deeper groundwater originated from an off-site source.
Trinity submitted a Site Assessment and CSM Report to the CVRWQCB to document the investigation. Trinity recommended no further investigation of the deeper contamination due to its origin from an off-site source and recommended Soil Vapor Extraction (SVE) beneath the former dry cleaning suite to remediate the low concentrations of dry cleaning solvent present in shallow soil vapor. The CVRWQCB concurred with Trinity’s conclusions and recommendations.

NEXT STEPS:

Trinity has developed a RAP to address the Site Assessment and CSM Report recommendations. A 30-day public comment period will be sent to tenants and nearby property owners within 500 feet of the Site prior to approving the RAP.
Trinity will design, implement, and operate a SVE System until cleanup goals are met and the Site can receive case closure from the CVRWQCB. Trinity built a mini-SVE system that fits inside the building, saving on cost, increasing implementability, and providing security for the system.

CATEGORY OF SERVICE:

Helping our clients to receive fund remediation through the Site Cleanup Subaccount Program (SCAP) of the California State Water Resources Control Board.

TYPE OF CLIENT:

Private parties that are responsible for remediating contaminated properties, such as dry cleaners, industrial facilities, etc. The SCAP is a funding mechanism for responsible parties who lack sufficient financial resources to pay for the required investigation or cleanup of the existing or threatened surface or groundwater contamination.

BACKGROUND:

The Site Cleanup Subaccount Program (SCAP) is a funding program established by Senate Bill 445 (Hill, 2014), allowing the State Water Resources Control Board to issue grants to fund projects that remediate the harm or threat of harm to human health, safety, or the environment caused by existing or threatened surface water or groundwater contamination. The evaluation process includes consideration of the degree of threat, whether the site is located in a small or disadvantaged community, the cost and benefits of the cleanup, and the financial resources of the responsible parties.

CLIENT GOALS:

The owner of project location where surface or groundwater contamination occurred is financially responsible for cleanup. The SCAP can provide funding for the cost of the investigation and the cleanup.

PROJECT APPROACH:

Trinity submits a complete Groundwater Quality Funding Program Pre-Application via Financial Assistance Application Submittal Tool (FAAST).
As the site evaluation proceeds through the SCAP process, Trinity provides support including scopes of work and cost estimates for State approval.
Trinity works actively with the oversight agency to gain approval for the scope of work and costs, and participates on the contract negotiation.
Trinity tracks the progress of reimbursement requests through the electronic submittal system. If additional documentation is requested, Trinity provides the information on behalf of the owner of the contaminated site.
As the cleanup project proceeds, Trinity uploads reimbursement requests to the SCAP utilizing their electronic submittal procedure. The reimbursement requests typically cover progress payments.

CATEGORY OF SERVICE:

Industrial Manufacturing Solvents - Assessment and Remediation, Santa Cruz, California

TYPE OF CLIENT:

Private Owner – Multi-Tenant Commercial Building

Assessment and remediation, santa cruz, california

BACKGROUND:

The site is a former retail display manufacturing and metal plating facility and has been subject to environmental assessment and remediation for many years. A plume of dissolved halogenated volatile organic compounds (HVOCs) with 1,4-dioxane has been identified in groundwater beneath the existing industrial building, and multiple remediation events in various portions of the plume have been performed. The remediation activities by previous consultants have included subsurface injections of RegenOx, 3DMe, hydrogen-releasing compound, and persulfate with sodium hydroxide activator, at various times and locations. These remedial efforts have not effectively reduced the dissolved contaminant plume concentrations beneath the building, as significantly elevated HVOC concentrations remain in groundwater monitoring wells.

CLIENT GOALS FOR PROJECT:

The client required assistance to assess soil and groundwater data gaps and perform additional remediation to clean up the dissolved contaminant plume in order to achieve site closure from the Central Coast Regional Water Quality Control Board (CCRWQCB).

The site is considered to be a candidate for thermal remediation with soil vapor extraction to remediate the residual dissolved plume. The environmental work was estimated to cost more than three million dollars and was contingent upon the client receiving additional funding. With Trinity’s assistance, the client applied for funds through the State of California Site Cleanup Subaccount Program (SCAP). The SCAP allows the State Water Resources Control Board to issue grants to fund projects for responsible parties who lack sufficient financial resources to pay for the required environmental investigation and remediation. The client received grant approval from SCAP, and Trinity is currently conducting the data gaps assessment and remedial design.

Click here for more information on how Trinity can assist with obtaining grants from SCAP.

PROJECT APPROACH:

Conduct soil vapor delineation.
Conduct subsurface assessment activities utilizing Membrane-Interface Probe (MIP) to determine the three-dimensional extent and mass of HVOCs and 1,4-dioxane in soil and groundwater, and confirm the depth and configuration of bedrock surface beneath the site.
Prepare a Remedial Action Plan (RAP) proposing thermal remediation with soil vapor extraction to remove HVOCs and 1,4-dioxane from soil, groundwater, and soil vapor.
Upon CCRWQCB approval of the RAP, complete system installation, and operate system for six months or more as needed to achieve remedial goals.
Perform post-remediation confirmation sampling and groundwater monitoring to verify the effectiveness of the remedial effort to the satisfaction of the client and the CCRWQCB.

NEXT STEPS:

Continue groundwater monitoring of plume.
Complete site assessment to close data gaps.
Prepare a request for proposal to obtain competitive bids for the thermal remediation
Establish proposed cleanup goals for site chemicals of concern
Prepare a Remedial Action Plan.
Oversee construction, operation, and maintenance of the thermal remediation system
Track progress of SCAP reimbursements throughout duration of environmental work.
